RDRY-850A
Machine Advantages
Designed for Paper Cup & Food Packaging Printing
The RDRY-850A Flexographic Printing Machine is designed for paper cup manufacturers, paper bowl producers, converters, and packaging distributors seeking stable print quality, reliable registration accuracy, and efficient roll-to-roll production. It provides an ideal solution for printing paper cup fans, bowl blanks, bucket materials, and food packaging paper before die cutting and forming.
High-Quality Brand Printing
- Supports 2, 4, 6, and 8 color printing configurations.
- Suitable for logos, product graphics, and food packaging artwork.
- Provides consistent color reproduction and clean print quality.
Food Packaging Production Ready
- Compatible with water-based food-grade inks.
- Supports PE coated paper, PLA paper, and food packaging board.
- Suitable for environmentally friendly packaging projects.
Support for Buyers & Distributors
- Help determine suitable machine width and color configuration.
- Support complete printing, die cutting, and forming line planning.
- Installation, training, spare parts, and technical support worldwide.
Specifications
RDRY Series Flexographic Printing Machine Specifications
The following specifications are provided as a reference. Machine width, color stations, and configurations can be customized according to production requirements.
| Item | RDRY-850A | RDRY-950A | RDRY-1000A |
|---|---|---|---|
| Color Stations | 2 / 4 / 6 / 8 Colors | ||
| Printing Speed | 55–60 m/min | ||
| Maximum Web Width | 860 mm | 950 mm | 1010 mm |
| Maximum Printing Width | 850 mm | 940 mm | 1000 mm |
| Maximum Unwind Diameter | 1300 mm | ||
| Print Repeat Length | 175–380 mm | ||
| Registration Accuracy | ±0.10 mm | ||
| Total Power | 45 KW | 45 KW | 50 KW |
| Air Pressure | 0.6–0.8 MPa | ||
| Voltage | 380V ±10% | ||
| Machine Weight | 4500 Kg | 5000 Kg | 5500 Kg |
| Machine Dimensions | 4800 × 2050 × 2250 mm | 4800 × 2150 × 2250 mm | 4800 × 2250 × 2250 mm |
| Customization | Machine width, color stations, drying systems, and configurations can be customized. | ||
Download Product Information
Materials & Applications
Compatible Materials & Paper Packaging Applications
The RDRY Series Flexographic Printing Machine is designed for food packaging converters and paper container manufacturers. It supports various paper materials commonly used for paper cups, paper bowls, paper buckets, and takeaway packaging products.
Compatible Printing Materials
Single/Double PE Coated Paper
Commonly used for hot beverage paper cups and food containers.
PLA Coated Paper
Eco-friendly and compostable material for sustainable packaging projects.
Kraft Paper
Popular for natural-style food packaging and takeaway containers.
Food-Grade Paperboard
Suitable for premium paper cups, bowls, and food packaging products.
Typical Applications
Paper Cups
Hot and cold beverage packaging
Paper Bowls
Noodle bowls and takeaway food containers
Paper Buckets
Popcorn tubs and fried chicken buckets
Food Packaging
Takeaway and restaurant packaging products
Typical Paper Cup Production Workflow
Artwork Design
Create logos, branding, and packaging graphics
Flexographic Printing
RDRY Series paper cup printing machine
Die Cutting
Convert printed rolls into paper cup fan blanks
Cup Forming
Paper cup forming machine production
Inspection & Packing
Quality control, counting, and packaging
Machine Video
Watch the RDRY Series Printing Paper Cup Materials in Production
See how the flexographic printing system delivers stable registration, clean graphics, and reliable performance for paper cup, paper bowl, and food packaging production.
High-Precision Printing Observe multi-color printing performance, registration accuracy, and print quality during production.
Food Packaging Materials Review printing on PE-coated paper, PLA-coated paper, kraft paper, and food-grade paperboard.
Production Line Integration See how printed rolls move to die cutting and cup forming processes for complete paper cup production.
FAQ
Paper Cup Printing Machine FAQs
Answers for manufacturers, distributors, and project buyers evaluating paper cup printing equipment and production line configurations.
How many colors do I actually need?
Most paper cup projects use 4-color printing. If your designs contain complex graphics, gradients, or multiple brand colors, 6-color or 8-color configurations may be more suitable.
How do distributors determine the correct machine configuration?
RUIDA Machine helps evaluate customer artwork, production volume, material specifications, and future expansion plans before recommending a suitable model and color configuration.
Can the machine print paper bowls and paper buckets?
Yes. The machine can print materials used for paper cups, paper bowls, paper buckets, and many other food packaging products.
What ink types are supported?
The machine is optimized for water-based inks commonly used in food-grade packaging production.
Can the machine work with PLA-coated paper?
Yes. PLA-coated paper, PE-coated paper, kraft paper, and food-grade paperboard can all be processed.
What is registration accuracy?
The machine provides registration accuracy up to ±0.10 mm, helping maintain consistent print quality and reducing material waste.
Can a complete production line be supplied?
Yes. RUIDA Machine can provide printing machines, die cutting machines, paper cup forming machines, inspection equipment, and complete production line planning.
Do you provide support for distributors?
Yes. We provide product documents, machine videos, technical support, training assistance, certification documents, and project consultation for distributors worldwide.
Can engineers provide on-site installation?
Yes. Installation, commissioning, operator training, and after-sales support are available for overseas projects.
Can machine specifications be customized?
Yes. Machine width, color stations, drying systems, and other configurations can be customized according to production requirements.
Send Inquiry
Get a Suitable Machine Recommendation
Tell us your target paper packaging product, material, size range, and capacity requirement. Ruida Machine will help recommend suitable equipment and production workflow options.
- Machine recommendation based on product type and material.
- Production line planning for printing, die cutting, forming, and packing.
- Support for machine configuration, molds, installation, and startup.
