RDRY-850C-4C
Machine Advantages
Print & Die Cut Paper Cup Fans in One Production Line
The RDRY-850C-4C combines flexographic printing and die cutting into a single automated production line. Instead of transferring printed rolls between multiple machines, manufacturers can produce finished paper cup fan blanks directly from raw material rolls, reducing labor costs, production time, and factory space requirements.
Integrated Production Workflow
- Printing and die cutting completed in one continuous process.
- Reduces handling between production stages.
- Improves overall production efficiency and workflow stability.
Lower Labor & Factory Costs
- Eliminates separate printing and punching operations.
- Reduces labor requirements and production lead time.
- Compact layout saves valuable workshop space.
Support for Global Buyers
- Help determine whether integrated or separate production lines are more suitable.
- Assist distributors with customer requirement analysis.
- Installation, training, spare parts, and technical support available worldwide.
Specifications
RDRY-850C-4C Technical Specifications
The following specifications are provided as a reference for the RDRY-850C-4C In-line Flexo Printing & Die Cutting Machine.
| Item | Specification | Buyer Consideration |
|---|---|---|
| Printing Section | ||
| Printing Speed | 40 m/min | Suitable for continuous paper cup fan production. |
| Printing Colors | 4 Colors | Ideal for most paper cup branding and food packaging designs. |
| Maximum Printing Width | 850 mm | Supports various cup and bowl blank layouts. |
| Maximum Web Width | 860 mm | Compatible with standard food packaging paper rolls. |
| Maximum Roll Diameter | 1300 mm | Allows long production runs and fewer material changes. |
| Printing Length | 180–380 mm | Suitable for various product dimensions. |
| Registration Accuracy | ±0.10 mm | Ensures accurate print positioning and color registration. |
| Printing Power | 30 KW | Optimized for industrial-scale production. |
| Die Cutting Section | ||
| Die Cutting Speed | 200–350 Times/Min | High-output paper cup fan production. |
| Maximum Feeding Width | 860 mm | Matches printing section for continuous workflow. |
| Maximum Die Cutting Area | 400 × 850 mm | Supports multiple fan layouts and product sizes. |
| Locating Accuracy | ±0.10 mm | Ensures precise alignment with printed graphics. |
| Die Cutting Power | 8.5 KW | Stable cutting performance under continuous production. |
| Lubrication System | Manual | Simple maintenance and operation. |
| Air Pressure | 0.6 MPa | Required for stable machine operation. |
| Voltage | 380V ±10% | Can be customized according to local standards. |
| Machine Dimensions | 3500 × 1300 × 2350 mm | Compact integrated structure reduces floor space requirements. |
| Customization | Available | Printing colors, widths, and die-cutting molds can be customized. |
Download Product Information
Materials & Applications
Compatible Materials & Paper Cup Fan Applications
The RDRY-850C-4C is designed for integrated paper cup fan production, supporting both traditional and eco-friendly packaging materials used in disposable food packaging industries.
Compatible Materials
Single PE Coated Paper
Most common material for hot beverage cups and food containers.
Double PE Coated Paper
Suitable for cold drinks, ice cream cups, and moisture-resistant packaging.
PLA Coated Paper
Biodegradable packaging material for sustainable projects.
Kraft Paper
Popular for environmentally conscious food packaging brands.
Typical Applications
Paper Cup Fans
Ready-to-form paper cup blanks
Paper Bowl Blanks
Noodle bowls and takeaway food packaging
Paper Plate Blanks
Disposable tableware production
Ice Cream Cone Blanks
Conical food packaging production
Integrated Paper Cup Fan Production Workflow
Artwork Design
Create branding, logos, and packaging graphics
Roll Feeding
Load PE coated paper or food-grade packaging materials
Flexographic Printing
Print graphics using 4-color flexographic technology
Inline Die Cutting
Automatically convert printed rolls into cup fan blanks
Fan Collection
Collect finished blanks ready for cup forming
Cup Forming
Transfer directly to paper cup production machines
Machine Video
Watch the RDRY-850C-4C Printing & Die Cutting Paper Cup Fans in One Process
See how paper rolls are printed, die cut, and converted into finished paper cup fan blanks without transferring materials between multiple machines.
Integrated Production Workflow Observe printing and die cutting completed in one automated production line.
Accurate Registration & Cutting Review registration accuracy and alignment between printed graphics and die-cutting positions.
Ready-to-Form Cup Fans Check finished paper cup fan quality before transfer to paper cup forming machines.
FAQ
In-line Printing & Die Cutting Machine FAQs
Common questions from paper cup manufacturers, distributors, and project buyers evaluating integrated printing and die-cutting solutions.
Should I choose an integrated machine or separate printing and die-cutting machines?
If your priority is reducing labor, saving factory space, and simplifying production management, an integrated machine is usually the better choice. Separate machines may be suitable for very large factories requiring maximum production flexibility.
Why are many buyers unsure which configuration they need?
Most buyers understand the final paper cup product but not the production process. RUIDA Machine helps evaluate cup size, artwork complexity, production volume, and future expansion plans before recommending equipment.
Is 4-color printing enough for paper cup production?
For most coffee cups, beverage cups, and food packaging brands, 4-color printing is sufficient. More complex designs may require 6-color or 8-color configurations.
Can the machine produce paper bowl blanks?
Yes. By changing tooling layouts, the machine can produce paper bowl blanks, paper plate blanks, and other food packaging components.
Is it worth investing in a complete production line?
For manufacturers planning long-term production, a complete line usually provides better production efficiency, lower labor costs, and easier quality control compared to purchasing equipment separately over time.
Can RUIDA Machine provide complete production line planning?
Yes. We provide printing machines, die-cutting machines, paper cup machines, inspection systems, packing equipment, and complete factory layout recommendations.
What materials are supported?
Single PE paper, double PE paper, PLA-coated paper, kraft paper, and various food-grade packaging papers.
Can the machine be customized?
Yes. Printing colors, machine width, die-cutting layouts, and other configurations can be customized according to production requirements.
Do you provide installation and training services?
Yes. We provide installation guidance, commissioning, operator training, spare parts support, and long-term technical assistance worldwide.
Can distributors receive technical support?
Yes. We help distributors understand customer requirements, recommend suitable configurations, and provide product documents, videos, and technical support.
Send Inquiry
Get a Suitable Machine Recommendation
Tell us your target paper packaging product, material, size range, and capacity requirement. Ruida Machine will help recommend suitable equipment and production workflow options.
- Machine recommendation based on product type and material.
- Production line planning for printing, die cutting, forming, and packing.
- Support for machine configuration, molds, installation, and startup.
